Connectwell CYDLG2.5EX, 2.5 mm², Double-level feed-through and ground terminal block, Green/Yellow, For Ex e applications
In stock
The Connectwell CYDLG2.5EX is a double-level feed-through and ground terminal block in the CY series, designed for 35 mm DIN-rail control-panel wiring. It uses screw-clamp connections and a polyamide 6.6 housing.
- Rated conductor size: 2.5 mm²
- Conductor range: 0.2–2.5 mm² stranded; 0.2–4 mm² solid
- AWG range: 24–12 AWG stranded; 24–10 AWG solid
- Connections and levels: 4 connections across 2 levels
- Dimensions: 5 mm wide × 70.5 mm long; rail height 65.9 mm / 73.4 mm
- Colour: Green/Yellow
- Electrical rating: IEC: Top level: 500 V, 24 A; lower level: protective earth; UL/CSA: Top level: 300 V, 20 A
- Wire stripping length: 8 mm
- Tightening torque: 0.4 Nm
- Standards: IEC 60947-7-1 / IEC 60947-7-2; UL 1059
- Special function: Top level is feed-through; lower level provides a DIN-rail protective-earth connection.
- Hazardous-area version: For Ex e applications. Use only in accordance with the applicable approval, certificate and installation requirements.
Suitable for industrial control panels, machinery, power distribution, instrumentation and automation systems where secure, serviceable DIN-rail connections are required.
